Mitsubishi Pajero NM, NP, NS, NT, NW, NX (2000 on) - Dobinsons IMS

Dobinsons IMS monotube shock absorbers are designed for next level performance over twin tube shocks in those hot, harsh, demanding conditions. By utilising the monotube design, Dobinsons IMS shock absorbers are able to resist fade far longer on corrugated roads, long or hard working 4WD trips, towing or racing conditions. The larger 50 and 60mm high flow pistons reduce internal pressures, reduce the heat generated, transfer heat to the body for faster cooling and offer improved damping performance and vehicle control at higher shaft speeds on rough terrain and during big impacts. Threaded bodies on struts allow for fine tuning of height and offer further improvements in cooling. The micro polished, hard chromed and heat treat shock shaft, CNC aluminium high flow race inspired piston, and DOM seamless tubing body provides the ultimate in performance and off-road durability. Composite piston wear bands, high quality Fuchs oil and a race style 3-stage sealing system offer the lowest levels of friction whilst maintaining durability and longevity without the need for frequent rebuilding or servicing. Dobinsons team of engineers spend hundreds of hours of testing and tuning the shim stacks and damping Characteristics in each IMS shock to ensure a balance of comfort, handling, vehicle control and off-road performance - Enjoy the ride.

Make	Mitsubishi
Model Series	Pajero V7 (NM, NP, NS, NT, NW, NX)
Year Compatibility	2000 Onwards
Shock Absorber Type	Dobinsons IMS Monotube
Lift Height	40-50mm Front
Piston Diameter	50/60mm CNC Machined Billet Aluminium
Shock Body O.D.	56mm / 66mm Seamless DOM Tubing
Spring Seat	T6 6061 Height Adjustable
Sealing System	Heavy Duty 3 Stage FKM HNBR
Corrosion Resistance	EDP Surface Protection
